FCC58 FeCoCu Pre Alloyed Metal Powder For High Quality Diamond Tools

FCC58 FeCoCu Pre Alloyed Metal Powder For High Quality Diamond Tools

1. What is Pre-alloyed Powder

Pre-alloyed powders are harder, less compressible and hence require higher pressing loads to produce high density compacts. However, they are capable of producing high strength sintered materials. Pre-alloying is also used when the production of a homogeneous material from elemental powders requires very high temperatures and long sintering times. The best examples are the stainless steels, whose chromium and nickel contents have to be pre-alloyed to allow economic production by powder metallurgy.

2. The Parameters of FCC58

	Main Element	Fe, Co, Cu
	Theoretical Density	8.58g/cm³
	Sintering Temperature	850℃
	Bending Strength	1400Mpa
	Hardness	98-102HRB

3. FCC58 Pre-alloyed Powder Character

• The powder has good wetting ability to the diamond and great mechanical granulating to other metal powders, the bond has a high toughness, strong impact resistance.
• Can be used on high quality diamond tools produciton, such as the diamond wire, diamond core bits, high quality granite saw blade, ceramic cutting blade

4. Usage Instruction for High Quality Ceramic Cutting Blade

1. Metal Powder

• 30-50% FCC58
• + 3-8% Ni
• +25-35% Cu
• + 5-8% Sn
• + Fe for the balance

    B. Diamond

• 50/60 @ 30%
• 60/70 @ 40%
• 70/80 @30%
• Diamond Concentration @ 9-12%

    C. Sintering Temperature  840-860℃
